The C 150 sets new standards for cell cultivation: contamination-free as a result of hot air sterilization at 180 °C, stable pH thanks to a drift-free FPI infrared measurement system, superior temperature precision with excellent dynamics, and an interior that is condensation-free even at high humidity levels to ensure best growth results. Used stand alone or as a stack the C 150 is easily accessible.
Exterior dimensions
Width (mm/inch) 680 / 26.8
Height (mm/inch) 819 / 32.2
Depth (mm/inch) 815 / 32.1
plus door handle, I-triangle (mm/inch) 54 / 2.1
plus mains- and gas connection (mm/inch) 60 / 2.4
Wall clearance rear (mm/inch) 100 / 3.9
Wall clearance side (mm/inch) 50 / 2.0
Interior dimensions
Width (mm/inch) 500 / 19.7
Height (mm/inch) 600 / 23.6
Depth (mm/inch) 500 / 19.7
Interior volume (l/cu.ft.) 150 / 5.4
Perforated shelves, stainless steel (number
standard/max.)
3 / 6
Dimensions of perforated shelves, width x
depth (mm)
491 x 442
width x depth (inch) 19.3 x 17.4
Weight of the unit (kg/lbs.) 95 / 209
Temperature / CO2 data
Temperature range, 7 °C (44,6 °F) above
ambient up to °C / °F
50
Temperature variation at 37 °C (98.6 °F) (±
°C)
0.4
Temperature fluctuation (± °C) 0.1
Recovery time after door was opened for 30
sec. at 37 °C (98.6 °F) (Min) 1)
5
CO2 data
CO2-range (Vol.-% CO2) 0 – 20
Setting accuracy (Vol.-% CO2) 0.1
Recovery time after door was opened for 30
sec. up to 5 vol. % (Min) 1) 2)
7
CO2 measurement IR
Hose connectors for CO2 (mm/inch) 6
Humidity data
Humidity (average values) (±2 % RH) 95 (±2)
Electrical data
Housing protection acc. to EN 60529 IP 20
Nominal voltage (±10 %) 50 / 60 Hz (V) 230 / 100
Nominal power (kW) 1.4
Energy consumption 2) at 37 °C (W) 1 1 0
